15 Working with image modes
Image mode
Picture in picture
Digital camera

15.3 Selecting the image mode

Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
3. Push the joystick to display a submenu.
4. Use the joystick to go to one of the image modes:
• (Thermal MSX)
• (Thermal)
• (Picture in picture)
• (Digital camera)
5. Push the joystick confirm.
6. If Picture in picture mode is selected, you can at this point move and resize the image
frame using the touch screen.
#T559880; r. AK/36075/36075; en-US
(Image mode).
