16 Working with measurement tools
3. Push the joystick to display a submenu. Use the joystick to select one or more of the
global object parameters:
• (External IR window compensation)
• (Object distance)
• (Atmospheric temperature)
• (Relative humidity)
• (Reflected temperature)
• (Emissivity)
4. Push the joystick to display a dialog box.
5. Use the joystick to change the parameter.
6. Push the joystick. This closes the dialog box.
16.5.4.2 Changing local parameters
You can change the local parameters for a measurement tool.
A P next to the measurement tool on the screen indicates that local parameters are acti-
vated for the tool.
Follow this procedure:
1. To select the measurement tool, touch the tool on the screen. The tool is now dis-
played with one or more handles.
2. Push the joystick—or touch and hold the tool. This displays a context menu.
3. Use the joystick to go to
4. Push the joystick.
5. Push the joystick to activate the use of local parameters.
tor) is displayed together with a submenu.
6. Use the joystick to select an object parameter.
7. Push the joystick to display a dialog box.
8. Use the joystick to change the parameter.
9. Push the joystick. This closes the dialog box.
10. When completed, push the joystick and select

16.5.5 Related topics

For in-depth information about parameters, and how to correctly set the emissivity and
reflected apparent temperature, see section 31 Thermographic measurement techni-
ques, page 467.

16.6 Displaying values in the result table and displaying a graph

16.6.1 General

For the box, circle, and line tools, you can set the camera to display the maximum, mini-
mum, and average values in the result table.
For the line tool, you can also display a graph.
#T559880; r. AK/36075/36075; en-US
(Use local parameters).
(icon with grey indicator) is displayed.
(Done).
(icon with blue indica-
46
