Contec IPC Series User Manual page 37

4. About the RAID Building Software
(6) After checking that the mirroring has been set, press [Esc] key.
Array No.
Array 0
(7) Press [Esc] key in [Setup Utility] main menu.
Auto Configuration......................[1]
Define RAID..............................[2]
Delete RAID..............................[3]
Rebuild RAID............................[4]
RAID Card Configuration..............[5]
(8) When you are asked whether to exist [Setup Utility], press [Y] key to exit [Setup Utility].
Exit Setup Utility! Are you sure?
Press Y to exit or ANY KEY to go back.
(9) Your PC will be rebooted. After Windows startup, format the CF which mirroring has been set.
When formatting, the established two CFs will be formatted.
32
[Define RAID Menu]
Array Mode Drive No.
Mirror
Size(MB)
2 977
Status
Functional
PC-RSD Series
