Installing Windows XP newly
on a hard disk or this product
CAUTION
- When installing drivers of this product while installing Windows XP newly on a hard disk, remove
the CF of this product in Step 1. When installing Windows XP on the CF of this product, do not
remove the CF in Step 1.
- The board cannot be properly installed unless the resources (I/O addresses and interrupt level) for
the board can be allocated. Before attempting to install the board, first determine what PC
resources are free to use.
- More than one product cannot be used on the same PC.
- When installing OS on this product, make sure to prepare the CF having the capacity larger than
that required by OS.

Installing drivers while installing Windows XP newly

(1) After completing the board mounting, turn on the PC. A message saying "IT8212 RAID... " will
be displayed after a period of time. At this time, RAID setting is not performed, so press [Esc]
key. Without pressing [Esc] key, the status will become startup status after a period of time.
(2) When installing from floppy disk, start up your PC from the "Windows XP installation disk".
When installing from CD-ROM, start up you PC from CD-ROM.
When a message "Press F6 if you need to install third party SCSI or RAID driver" is displayed,
press [F6] key.
(3) After [Windows XP setup] is displayed, press [S] key to specify a driver you want to add.
(4) Insert the supplied Driver FD into the floppy drive and press [Enter] key.
(5) Select "CONTEC PC-RSD Series (Windows XP)" from a list displayed on the screen and press
[Enter] key.
(6) [Windows XP setup] screen is displayed again and a message saying "Setup will load support for
the following mass storage device(s)" is displayed. [CONTEC PC-RSD Series (Windows XP)]
is now included in this list.
If any additional device you want to install, specify it now. If all devices are specified, proceed
to the next step.
(7) Press [Enter] key on [Windows XP setup] screen to continue the Windows XP installation. In the
middle of installation, the Windows XP installation location can be selected from either the CF of
this product or PC hard disk.
