2. Setup
(7) Press [Enter] key on [Windows 2000 setup] screen to continue the Windows 2000 installation. In
the middle of installation, the Windows 2000 installation location can be selected from either the
CF of this product or PC hard disk. The message "Cannot find digital signature" appears in the next
window. Ignore this and click "Yes".
CAUTION
In the middle of installation of the Windows 2000, the Hardware Wizard displays the alert dialog
box. This dialog box appears, only indicating that the relevant driver has not passed Windows
Logo testing, and it can be ignored without developing any problem with the operation of the board.
In this case, click on the [Yes] button.
You have now finished installing the Hardware.
After installing Windows 2000 on the hard disk, shutdown the system and mount the removed CF back
to the slot.

Check Method of Hardware Install Completion

(1) Click the [Start] button on the left side of task bar
and then double click the [System] from the
[Setting]→[Control Panel].
(2) When the [System propaties] is displayed, click the
[Hardware] tab and then click the [Device
Manager].
(3) Check if the board name has been registered
correctly in [SCSI and RAID controllers].
(4) Check if [ITE Disk Array 0 SCSI Disk Device] has
been registered in [Disk Drives].
Once it is verified that the hardware is listed on Disk Drive, it can be used as a disk drive. Drive
mapping depends on the state of the PC used (BIOS settings and IDE device connection status).
CAUTION
When formatting CF on Windows 2000, do not format it as a "dynamic disk". If CF is formatted as
a "dynamic disk", it cannot be used on other PCs or OSs.
