2.3

CP-Parameter for open-loop operation

Parameter
CP00 Password input
CP01 Actual value display
CP02 Set frequency display
CP03 Inverter state
CP04 Apparent current
CP05 Apparent current peak value
CP06 Actual utilization
CP07 Actual DC voltage
CP08 DC link voltage peak value
CP09 Output voltage
CP10 min. reference forward
CP11 max. reference
CP12 acc. time forward
CP13 dec. time forward (-1=CP12)
CP14 S-curve time acc.
CP15 Boost
CP16 Rated frequency
CP17 Voltage stabilization
CP18 Switching frequency
CP19 step value 1
CP20 step value 2
CP21 step value 3
CP22 DC braking mode
CP23 DC braking time
CP24 LAD load level
CP25 Stall level
CP26 Speed search condition
CP27 Motor protect. function response 0...6
CP28 Motor protection mode
CP29 motorprot. rated current
CP30 ANOUT1 function
CP31 ANOUT1 gain
CP32 Condition SB0
CP33 Condition SB2
CP34 comparison level 2
CP35 AN1 interface selection
CP36 select 50Hz/60Hz mode
CP37 warning dOH stop. mode
CP38 Inverter address
CP39 last error
CP40 parameter set copy function
CP48 Software version
LTK=depending on power unit; E=ENTER-Parameter; R=read only
CP-Parameter for open-loop operation
Range
0...9999
-400...400
-400...400
0...255
0...6553,5
0...6553,5
0...400
0...1000
0...1000
0...778
0...400
0...400
0,00...300,00
-0,01...300,00
0,00...5,00
0,0...25,5
0...400
0...649
0...LTK
-400...400
-400...400
-400...400
0...506
0,00...100,00
0...200
0...200
0...31
0...1
0,0...370,0
0...26
-20,00...20,00
0...101
0...101
±30000,00
0...2
0...1
0...8
0...239
0...255
-4...7
x.x.x.x
Resolu-
Default Unit Flag
tion
1 - -
0,0125 0 Hz
0,0125 0 Hz
1 0 -
0,1 0 A
0,1 0 A
1 0 %
1 0 V
1 0 V
1 0 V
0,0125 0 Hz
0,0125 70 Hz
0,01 5 s
0,01 5 s
0,01 0 s
0,1 LTK %
0,0125 50 Hz
1 off V
1 LTK -
0,0125 5 Hz
0,0125 50 Hz
0,0125 70 Hz
1 7 -
0,01 10 s
1 140 %
1 200:off %
1 8 -
1 6 –
1 1 –
0,1 LTK A
1 2 –
0,01 1 –
1 20 –
1 4 –
0,01 100,00 –
1 0 –
1 0 –
1 7 –
1 0 –
1 0 –
1 0 –
– LTK –
based
on
- Ud01
R ru07
R ru01
R ru00
R ru15
R ru16
R ru13
R ru18
R ru19
R ru20
- oP06
- oP10
- oP28
- oP30
- oP32
- uF01
- uF00
E uF09
E uF11
- oP21
- oP22
- oP23
E Pn28
- Pn30
- Pn24
- Pn20
E Pn26
– Pn14
– dr11
– dr12
E An31
– An33
E do00
E do02
– LE02
E An00
E Ud06
– Pn12
– Sy06
E, R In24
– Fr01
R In06
