CP04 Apparent current

Co-domain
0...±6553.5 A

CP05 Apparent current peak value

Co-domain
0...±6553.5 A

CP06 DC link voltage peak value

Co-domain
0...400 %

CP07 Actual DC voltage

Co-domain
0...1000 V
CP-Parameter for open-loop operation
Description
Display of the actual apparent current in ampere.
Description
CP05 makes is possible to recognize the max. apparent current. For that
the highest value of CP04 is stored in CP05. The peak value memory
can be cleared by pressing the UP, DOWN or ENTER key or via bus by
writing any value you like to the address of CP05. The switch off of the
inverter also clears the memory.
Description
Display of the actual inverter rate of utilization in percent. 100% rate of
utilization is equal to the inverter rated current. Only positive values are
displayed, meaning there is no differentiation between motor and gen-
eratoric operation.
Description
Display of actual DC-link voltage in volt. Typical values:
V-class Normal opera-
tion
230 V 290...360 V DC
400 V 510...620 V DC
Error!
Overvoltage
approx. 400 V DC
approx. 840 V DC
Error!
underpotential
approx. 216 V DC
approx. 240 V DC
11
