CP-Parameter for open-loop operation
CP00 Password input
see chapter 2.2

CP01 Actual value display

Co-domain
0...±400 Hz
18.3
-18.3

CP02 Set frequency display

Co-domain
0...±400 Hz

CP03 Inverter state

The actual operating condition of the inverter (e.g. forward constant run, standstill) is dis-
played in parameter „inverter state". In the case of an error the current error message is dis-
played, even if the display has already been reset with ENTER (status LED is still blinking).
Display
no operation
no direction of rota-
tion preset
Acceleration
Forward
Deceleration
Forward
Acceleration
Reverse
Deceleration
Reverse
Speed dependent
Forward
Speed dependent
Reverse
Other status messages are described at the parameters, on which they occur (see chapter
„Error Diagnosis").
10
Description
Display of the actual output frequency in Hz. The rotation of the inverter
is displayed by the sign.
Examples:
Output frequency 18,3 Hz, rotation forward
Output frequency 18,3 Hz, rotation reverse
Description
Display of actually set value. For control reasons the set speed is dis-
played, even if the control release or direction of rotation is not switched.
If no direction of rotation is set, the set frequency for clockwise rotation
(forward) is displayed.
State
modulation switched off; output voltage = 0 V; drive is not controlled.
modulation switched off; output voltage = 0 V; drive is not controlled.
drive accelerates with direction of rotation forward.
drive decelerates with direction of rotation forward.
drive accelerates with direction of rotation reverse.
drive decelerates with direction of rotation reverse.
Drive runs with constant speed and direction of rotation forward.
Drive runs with constant speed and direction of rotation reverse.
