Callout
Description
1
Server node 1
2
Server node 0
3
Storage shelf (DE3-24C)
4
Optional storage expansion shelf (DE3-24C)
Server Node Front Panel Features
The following figure shows the components on the front panel of an Oracle Database
Appliance X6-2-HA server node.
Oracle Database Appliance X6-2-HA Front and Back Panels
Chapter 2 • Overview of Oracle Database Appliance
25
