Supported Components and Capabilities
Component Oracle Database Appliance
X6-2S
SAS ports Two internal SAS3 ports
Onboard Two functional auto-sensing
Ethernet 100/1000/10000 Base-T
ports Ethernet ports with RJ-45
connectors located on the
back of the server.
Ethernet ports NET 2
Note -
and NET 3 are nonfunctional
in single-processor systems.
Network One 10/100/1000Base-T
management network interface port with
(NET MGT) RJ-45 connector dedicated to
port the service processor (SP) on
each server node rear panel.
Serial One RS-232 RJ-45 serial
management port on each server node rear
(SER MGT) panel.
port
VGA port One high-density HD-15
video port on each server
node rear panel.
14 Oracle Database Appliance Owner's Guide • March 2017
Oracle Database Appliance
X6-2M
Two internal SAS3 ports
Four auto-sensing
100/1000/10000 Base-T
Ethernet ports with RJ-45
connectors located on the
back of the server.
One 10/100/1000Base-T
network interface port with
RJ-45 connector dedicated to
the service processor (SP) on
each server node rear panel.
One RS-232 RJ-45 serial
port on each server node rear
panel.
One high-density HD-15
video port on each server
node rear panel.
Oracle Database Appliance
X6-2L
Two internal SAS3 ports
(only one used for rear
drives)
Four auto-sensing
100/1000/10000 Base-T
Ethernet ports with RJ-45
connectors located on the
back of the server.
One 10/100/1000Base-T
network interface port with
RJ-45 connector dedicated to
the service processor (SP) on
each server node rear panel.
One RS-232 RJ-45 serial
port on each server node rear
panel.
One high-density HD-15
video port on each server
node rear panel.
Oracle Database Appliance
X6-2-HA
on each server node through
two InfiniBand ports with
QSFP+ connections.
Alternatively, you have the
option of creating the node-
to-node interconnection
using two of each server
node's four 10 GbE network
interface ports with RJ-45
connections.
Note - This alternative
configuration is used
when the Oracle Database
Appliance X6-2-HA is
ordered with a Dual 10GbE
SFP+ PCIe 2.0 Low Profile
Adapter instead of the
standard InfiniBand adapter
when an Ethernet fiber
connection to the data
center or public network is
required.
Two internal SAS3 and four
external SAS3 ports on each
server node.
Six SAS3 ports on the
storage shelf.
Six SAS3 ports on the
storage expansion shelf.
Four auto-sensing
100/1000/10000 Base-T
Ethernet ports with RJ-45
connectors located on the
back of each server node.
One 10/100/1000Base-T
network interface port with
RJ-45 connector dedicated to
the service processor (SP) on
each server node rear panel.
One RS-232 RJ-45 serial
port on each server node rear
panel.
One high-density HD-15
video port on each server
node rear panel.
