External Midi - Code MINI 1000 User Manual

7.6.1. External Midi

In this mode, you should connect the controller with external MIDI equipment via the
MIDI cable first. And the controller should be set to 'Slave mode'.
1. Select [Time code Mode = External MIDI] and select a record key on Macro;
2. Press the soft-key
Play the music on external equipment. At this moment, the internal clock will change into
midi time code. It shows as followed.
3. Put out the playbacks or presets follow the rhythm as you want. If there is a Cue-lists
playback, you may use the function of GOTO to record.
4. Fade out all playbacks when the music finished. And press the soft-key
and save show record. Press [confirm] to save.
5. After saved, the window will list all the used playbacks and presets as well as the
operations.
6. The location of macro show and its record mode will be shown on top of the window.
7. Users may press the soft-key
show. But can also press the corresponding key on Macro section to run the macro if had
exited the window. The macro show is in ready state after selected the soft-key,
and wait for the MIDI signal to play. (Shown as photo below.) At the moment, the
time bar still show in internal clock.
MINI_1000_en.pdf
, it will turns red what means start to record
on record window when need to run the macro
42
.
to stop
http://www.codelight.com
