4.3. Use Preset

MINI 1000 provides several ways for users to recall the presets. The soft-key of latest
selected preset displays in gray green.
1> Select fixtures and recall: users can recall the preset after selected fixtures, those
fixtures without selected will not be added in the preset.
2> Non select fixtures and recall: users can recall the preset directly. In this case, all
fixtures which can use the preset will be added in the preset.
To recall the preset, if you had set the fade in time, it will use the time to fade in the preset;
if you had not set any time (default time is 0s), it will recall the preset immediately.
However, if you entry a value 0.0~200.0 (seconds) before recall the preset, it will use this
temporary time to fade in the preset.
Input value by numeric keys in
①
Select a preset on touch screen, such as a color mixed by RGB or a location;
②
Then you wi
③
You may also recall the preset by the number keys when you are selecting Preset key on
selection section. The information of the number keys will be shown on the external monitor.
Besides, you may also recall a preset by its number by typing the number on the numeric
keypad.
① Select Preset key on selection section;
② Type in the number of the preset you want to recall by numeric keypad;
③ Press Enter key.
You can only use its own fade in time by this operation. There is no way for you to entry
the value of temporary fade in time.
MINI_1000_en.pdf
"LIVE SHOW", such as number 5;
ll find the preset is recalled with fade in 5s.
