Move Function; Lock The Console; Record Macro Show - Code MINI 1000 User Manual

7.4. Move Function

It is easy to move the group, preset or playback to other position on MINI 1000. Press
Move and select a root, then select a target:
1. If it is an empty move target, you can achieve the move function;
2. If there is something in the move target, you can select [Overwrite it] or [Swap].
Note: Fixture can only be moved but can not be swapped.

7.5. Lock the Console

If you want to leave away for a moment, you can input the console with password in
numbers or letters in "LIVE SHOW", and then press [Lock Console]. When the console is
locked, any operation is uselessness unless input the right password.
Note: Restart can unlock the console.

7.6. Record Macro Show

Macro show is a function base on time code which allows users to record and replay a
sequence operate on the playbacks output. When record the show, users can select different
mode of time code as needed. MINI 1000 offers two kinds of time code modes for your choice.
① External MIDI ---- This mode needs a MIDI device to offer the time code to trigger the
show record. Please set the controller in to 'Slave Mode' before using this mode.
② Internal Clock ---- This mode should record and trigger the show record by the clock
base on the controller.
Users can replay the playbacks and presets by recall the macro show. When it is replaying,
the outputs of playbacks and presets are completed followed the operations when making the
macro show.
Press [Show Record Mode] on touch screen and select the mode of time code. At this
time, the option on selection part will switch to Macro. Then select a key for recording. The
gray bar upon will show where the record had put in.
