STM32F103xx
Figure 31. LQFP48 – 48 pin low-profile quad flat package outline
Table 45.
Dim.
A
A1
A2
b
C
D
D1
E
E1
e
θ
L
L1
N
1. Values in inches are converted from mm and rounded to 3 decimal digits.
D
D1
LQFP48 – 48 pin low-profile quad flat package mechanical data
mm
Min Typ
0.05
1.35 1.40
0.17 0.22
0.09
9.00
7.00
9.00
7.00
0.50
0° 3.5°
0.45 0.60
1.00
E1 E
L1
Max Min
1.60
0.15 0.002
1.45 0.053
0.27 0.007
0.20 0.004
7° 0°
0.75 0.018
Number of pins
48
Package characteristics
A
A2
A1
b
e
c
L
ai14399
(1)
inches
Typ Max
0.063
0.006
0.055 0.057
0.009 0.011
0.008
0.354
0.276
0.354
0.276
0.020
3.5° 7°
0.024 0.030
0.039
