Electrical characteristics
5.3.3 Embedded reset and power control block characteristics
The parameters given in
temperature and V
Table 9.
Symbol
V
PVD
V
PVDhyst
V
POR/PDR
V
PDRhyst
T
RSTTEMPO
5.3.4 Embedded reference voltage
The parameters given in
temperature and V
Table 10.
Symbol
V
REFINT
28/67
Table 9 are derived from tests performed under ambient
supply voltage conditions summarized in
DD
Embedded reset and power control block characteristics
Parameter
Programmable voltage
detector level selection
PVD hysteresis
Power on/power down reset
threshold
PDR hysteresis
Reset temporization
Table 10
supply voltage conditions summarized in
DD
Embedded internal reference voltage
Parameter
Internal reference voltage
Conditions
PLS[2:0]=000 (rising edge)
PLS[2:0]=000 (falling edge)
PLS[2:0]=001 (rising edge)
PLS[2:0]=001 (falling edge)
PLS[2:0]=010 (rising edge)
PLS[2:0]=010 (falling edge)
PLS[2:0]=011 (rising edge)
PLS[2:0]=011 (falling edge)
PLS[2:0]=100 (rising edge)
PLS[2:0]=100 (falling edge)
PLS[2:0]=101 (rising edge)
PLS[2:0]=101 (falling edge)
PLS[2:0]=110 (rising edge)
PLS[2:0]=110 (falling edge)
PLS[2:0]=111 (rising edge)
PLS[2:0]=111 (falling edge)
Falling edge
Rising edge
are derived from tests performed under ambient
Conditions
− 45°C < T
< +105°C
A
− 45°C < T
< +85°C
A
STM32F103xx
Table 7.
Min Typ Max Unit
2.1 2.18 2.26
2 2.08 2.16
2.19 2.28 2.37
2.09 2.18 2.27
2.28 2.38 2.48
2.18 2.28 2.38
2.38 2.48 2.58
2.28 2.38 2.48
2.47 2.58 2.69
2.37 2.48 2.59
2.57 2.68 2.79
2.47 2.58 2.69
2.66 2.78 2.9
2.56 2.68 2.8
2.76 2.88 3
2.66 2.78 2.9
100
1.8 1.88 1.96
1.84 1.92 2.0
40
1 2.5 4.5
Table 7.
Min Max
Typ
1.16 1.20 1.26
1.16 1.20 1.24
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
mV
V
V
mV
mS
Unit
V
V
