10
Other Functions
Exit/Reloop Button
AUTO CUE Button
Track Hot CUE Memory
Button
Track Hot CUE Button
Tempo Control Range
Button
Master Tempo Button
Tempo Adjustment Slider Adjusts the tempo (BPM) of each player. If you right click, the position becomes
Scratch Button
Jog Dial
Pitch Bend +/- Button
Loop/Reloop/AUTO CUE/
Master Tempo Display
Time Normal Button
Time Remain Button
Time Display
Tempo Display
BPM Display
BPM SYNC Button
TAP Button
Waveform Display
Track Hot CUE Tag
Index
Contents
After exiting a loop that is not being played: Resets the loop settings from memory.
While Playing a Loop: Returns to playing normally.
Toggles the Auto Cue function ON or OFF.
Toggles the Track Hot Cue Recording Mode ON or OFF.
During Playback Mode (while the track hot cue memory button is not lit):
1. With track hot cue settings made and player paused silently
Calls out the registered track hot cue and pauses.
2. With the track hot cue settings made and the player playing
Calls out the registered track hot cue and starts playing.
During Recording Mode (while the track hot cue memory button is lit):
1. While a Loop is Playing
Records the loop that is playing.
2. Other than while a Loop is Playing
Saves that position as a cue point.
Switches the maximum controllable tempo (BPM).
(10 16 W 6 10)
Toggles the Master Tempo function ON or OFF.
centered (±0).
Toggles the Scratch Mode ON or OFF.
While Playing: Makes fine adjustments to the tempo.
While Paused: Makes fine adjustments to the pause position.
Scratch Mode: Plays backwards & forwards while outputting the sound.
While Adjusting the Out Adjust: Makes fine adjustments to the loop out point.
Speeds up or slows down playback only for as long as it is held down.
It can be operated from the keyboard. (There is no button on the screen)
'4-5 Key Operations' P.67
Lights up while playing a loop, when a reloop is possible, when setting an auto cue,
while setting the master tempo.
Switches to elapsed time in the time display. (Lights up orange during settings.)
Switches to time remaining in the time display. (Lights up orange during settings.)
Displays the time of the song on the player.
Displays the value set by the tempo adjustment slider.
Displays either the BPM value detected automatically from the song on the player or
the BPM value detected based on the interval tapped in with the [TAP] button.
Toggles the BPM Synchro ON or OFF when in the slave mode.
Cannot be used when in the master mode.
The interval resulting from pressing the [TAP] button is reflected in measurement of
the BPM.
During Play: Moves the playback point to the selected point.
During Standby: Starts playing from the selected point.
While Paused: Moves the paused point to the selected point.
While Cued Up: Moves to the selected point and pauses.
Normally: Displays the registered cues, loop in and loop out points.
Table of Functions
(Contd. on the next page)
DJS Ver. 1.600
113
