2. On the Fault Detection page, enter values for the parameters indicated
Note
Web Page Item
Triggered Settings
Play Stored Audio Locally
Make Call to Extension
Dial Out Extension
Dial Out ID
Play Stored Audio via Multicast
Play Line-in Audio via Multicast
Multicast Address
Multicast Port
Play While Active
Times to Play
Note
CyberData Corporation
in Table 2-14.
The question mark icon (
after the Toggle Help button is pressed
Table 2-14. Fault Detection Configuration Parameters
You must click on the Save button and then the Reboot button for the changes to take
effect.
) in the following table shows which web page items will be defined
.
Description
When selected, the device will play the user defined "sensor
triggered" audio file when the fault detection is triggered.
When selected, the device will call an extension when fault
detection is triggered. Use the
the extension the device will call.
Specify the extension the device will call when fault detection is
triggered. Enter up to 64 alphanumeric characters.
An additional Caller identification string added to outbound calls.
Enter up to 64 alphanumeric characters.
When selected, the device will send the user-defined "sensor
triggered" audio file to the specified multicast address and port.
Cannot be combined with
When selected, the device will send line-in audio to the specified
multicast address and port. Cannot be combined with
Audio via Multicast or
The multicast address used for fault detection audio.
The multicast port used for fault detection audio.
Audio will be played via the selected method(s) for the duration of
the fault activation.
Number of times the fault detection audio will play (1-65535).
Click on the Test Fault Detection button to test the fault detection
feature.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some
of the web page items. First click on the Toggle Help button, and
you will see a question mark (
page items. Move the mouse pointer to hover over a question
mark to see a short description of a specific web page item.
931073B
Setting Up the Paging Server
Configure the Fault Detection Parameters
Dial Out Extension
Play Line-in Audio via
Enable Line-in to Line-out
) appear next to some of the web
Operations Guide
46
field to specify
Multicast.
Play Stored
Loopback.
