On the Network page, enter values for the parameters indicated in
Note
Web Page Item
Stored Network Settings
Addressing Mode
Hostname
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
DHCP Timeout in seconds
VLAN Settings
VLAN ID (0-4095)
VLAN Priority (0-7)
Current Network Settings
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
CyberData Corporation
The question mark icon (
after the Toggle Help button is pressed
Table 2-11. Network Configuration Parameters
931073B
) in the following table shows which web page items will be defined
.
Description
Select either DHCP IP Addressing or Static Addressing by marking
the appropriate radio button. DHCP Addressing mode is enabled on
default and the device will attempt to resolve network addressing with
the local DHCP server upon boot. If DHCP Addressing fails, the
device will revert to the last known IP address or the factory default
address if no prior DHCP lease was established. See
"Restore the Factory Default Settings"
sure to click Save and Reboot to store changes when configuring a
Static address.
This is the hostname provided by the DHCP server. See the DHCP/
DNS server documentation for more information. Enter up to 64
characters.
Enter the Static IPv4 network address in dotted decimal notation.
Enter the Subnet Mask in dotted decimal notation.
Enter the Default Gateway IPv4 address in dotted decimal notation.
Enter the primary DNS Server IPv4 address in dotted decimal
notation.
Enter the secondary DNS Server IPv4 address in dotted decimal
notation.
Specify the desired time-out duration (in seconds) that the device will
wait for a response from the DHCP server before reverting back to
the stored static IP address. The stored static IP address may be the
last known IP address or the factory default address if no prior DHCP
lease was established. Enter up to 8 characters. A value of -1 will
retry forever.
Specify the IEEE 802.1Q VLAN ID number. Enter up to 4 digits.
Note: The device supports 802.1Q VLAN tagging support. The
switch port connected to the device will need to be in "trunking mode"
for the VLAN tags to propagate.
Specify the IEEE 802.1p VLAN priority level. Enter 1 digit. A value of
0 may cause the VLAN ID tag to be ignored.
Shows the current network settings.
Shows the current Static IP address.
Shows the current Subnet Mask address.
Shows the current Default Gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
