CyberData 011146 Operation Manual page 31

2. On the Device page, you may enter values for the parameters indicated in
Note
Web Page Item
Line-in Settings
Enable Line-in to Line-out Loopback
Enable Line-in to Multicast
Multicast Address
Multicast Port
Detect Line-in Silence
Relay Settings
Activate Relay on Local Audio
Clock Settings
Set Time with NTP Server on boot
NTP Server
Posix Timezone String
Periodically sync time with server
Time update period (in hours)
Current Time
Misc Settings
Device Name
DTMF Duration
Beep on Init
CyberData Corporation
The question mark icon (
after the Toggle Help button is pressed
Table 2-6. Device Configuration Parameters
931073B
) in the following table shows which web page items will be defined
.
Description
Line-in audio will play back out the device's audio output
ports. This is the lowest priority audio and will be
preempted by any other audio stream.
Line-in audio will be sent to the specified multicast
address and port. Playback priority is determined by
receiver(s)
Cannot be combined with Play Line-in Audio via
Multicast (Fault Detection)
Address line-in audio will be sent to.
Port line-in audio will be sent to (1-65535).
If silence is detected on line-input, the multicast stream
will be stopped to reduce network traffic.
The relay will be activated (closed) when the device is
playing audio. Use this to activate an external amplifier
when the device is playing audio.
When selected, the time is set with an external NTP
server when the device restarts.
Use this field to set the address (in IPv4 dotted decimal
notation or as a canonical name) for the NTP Server. This
field can accept canonical names of up to 64 characters in
length.
See Section 2.4.5.2, "Time Zone Strings"
about how to use the Posix Timezone String to specify
time zone and daylight savings time where applicable.
Enter up to 63 characters.
When selected, the time is periodically updated with the
NTP server at the configured interval below.
The time interval after which the device will contact the
NTP server to update the time. Enter up to 4 digits.
Allows you to input the current time. (6 character limit)
Type the device name. Enter up to 25 characters.
The duration, in milliseconds, of DTMF tones played out of
the device's analog audio ports (0-65535).
Device will play the user defined "pagetone" audio file
when it boots.
Setting Up the Paging Server
Configure the Device Parameters
Table 2-6.
for information
Operations Guide
23
