Polycom Paging - CyberData 011146 Operation Manual

Web Page Item
Beep on Page
Enable Polycom Paging on Multicast
Polycom Transmit Channel
Disable HTTPS (NOT recommended)
Note

2.4.5.1 Polycom Paging

The Polycom Paging feature is supported on Polycom IP phones using UC Software 4.0.0 and
higher. The Polycom paging feature operates in two modes: Push-to-Talk (PTT) and Group Paging
Only Group Paging mode pages are supported by the Paging Server.
Polycom phones use the same multicast IP address and port number for both PTT and Group
Paging multicasts. Make sure to note the Polycom multicast IP address and port number before
configuring the CyberData V3 Paging Server. Polycom phones use a default multicast IP address of
224.0.1.116 and odd-numbered port 5001.
While the same multicast IP address and port number is used for all Polycom pages in both modes,
Polycom uses numbered "groups" or "channels" to differentiate between each paging group. Each
"group" or "channel" is numbered 1 through 25.
CyberData Corporation
Table 2-6. Device Configuration Parameters (continued)
You must click on the Save button and then the Reboot button for the changes to take
effect.
931073B
Description
Device will play the user defined "pagetone" audio file
before playing a SIP page.
Enabling Polycom Paging will result in a standard RTP
multicast being sent to the specified address and port and
a Polycom Group Paging multicast being sent to the
specified address and port+1.
Destination channel for Polycom Group Paging multicast.
Disables the encrypted connection to the webpage. We do
not recommend disabling HTTPS for security reasons.
Click on the Test Audio button to do an audio test. When
the Test Audio button is pressed, you will hear a voice
message for testing the device audio quality and volume.
This button will cause the device to send a 5 second
ULAW multicast stream to 234.2.1.200:2200.
Click on the Test Relay button to do a relay test.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description
of some of the web page items. First click on the Toggle
Help button, and you will see a question mark (
next to some of the web page items. Move the mouse
pointer to hover over a question mark to see a short
description of a specific web page item.
Setting Up the Paging Server
Configure the Device Parameters
) appear
Operations Guide
24
