00.077
RO Num
OL
0.00 to Drive HD Current Rating A
RFC-A
Displays the maximum heavy duty current rating of the drive.
00.078
RO Num
OL
RFC-A
Displays the software version in the drive.
00.079
RW Txt
OL
Open loop (1), RFC A (2)
RFC-A
Defines the mode of the drive.
00.081
RO Num
OL
-Pr 00.002 to Pr 00.002 or Pr 00.001
RFC-A
This is the basic reference selected from the available sources.
00.082
RO Num
OL
-Pr 00.002 to Pr 00.002 or Pr 00.001
RFC-A
The Pre-ramp Reference is the final output from the reference system that is fed into the ramp
system.
46
Maximum Heavy Duty Rating
Software Version
0 to 99.99.99.99
User Drive Mode
Reference Selected
to Pr 00.002 Hz
Pre-ramp Reference
to Pr 00.002 Hz
ND NC PT
ND NC PT
ND NC PT
Open loop (1)
RFC-A (2)
ND NC PT
ND NC PT
