00.035
RW Num
OL
RFC-A
Defines the behaviour of digital output 1 (terminal 10).
Value
0 User defined by Digital IO1 Source/Destination A
1 Drive running signal
2 Frequency arrived signal
3 Frequency level detection signal
4 Frequency level detection signal
5 Overload detection signal
6 Power off state
7 External fault stop
8 Frequency upper limit
9 Frequency lower limit
10 Drive running at zero frequency
14 Drive Ready
15 Drive OK
18 Brake release
19 Torque limiting (Valid while the torque is limited by torque limiting value 1/2)
20 Forward or reverse
21 Motor 1 or 2
36
DO1 Control
0-21
Description
