00.010
RW Num
OL
All Menus (2), Status Only (3),
RFC-A
This parameter controls access via the drive keypad as follows:
Value Text
0 Level 1
1 Level 2
2 All Menus
3 Status Only
4 No Access
00.011
RW Num
OL
RFC-A
This parameter changes the functions of the input terminals which are normally associated with the
enabling, starting and stopping the drive.
Pr 00.011
0 User programmable
1
2 User programmable
3
4
5 User programmable
6 User programmable
Action will only occur if the drive is inactive. If the drive is active, the parameter will return to its pre-
altered value on exit from edit mode.
Unidrive M400 Control Quick Start Guide
Issue Number: 3
User Security Status
Level 1 (0), Level 2 (1),
No Access (4)
Access to first 10 parameters in Menu 0 only.
Access to all parameters in Menu 0.
Access to all menus.
The keypad remains in status mode and no parameters can be
viewed or edited.
The keypad remains in status mode and no parameters can be
viewed or edited. Drive parameters cannot be accessed via a
comms/fieldbus interface in the drive or any option module.
Start/Stop Logic Select
0 to 6
Terminal 11 Terminal 12
Run Forward
/Stop Run Forward
/Stop
/Stop
Run Forward
programmable
ND NC
Function
Terminal 13
Run Reverse
Run Reverse
Run Forward/Reverse
Run Forward/Reverse
Run Jog Forward
Run Reverse
User User
programmable
PT US
Level 1 (0)
US
5
Latching
No
Yes
No
Yes
Yes
No
User
programmable
