Standard ramp is controlled deceleration to prevent DC bus over-voltage trips, normally used when
there is no braking resistor installed.
If a high motor voltage mode is selected, deceleration rates can be faster for a given inertia but motor
temperatures will be higher.
00.029
RW Bit
OL
RFC-A
Setting Pr 00.029 to 0 allows the user to disable the ramps. This is generally used when the drive is
required to closely follow a speed reference which already contains acceleration and deceleration
ramps.
00.030
RW Txt
OL
None (0), Read (1), Program (2),
RFC-A
* Only a value of 3 or 4 in this parameter is saved.
If Pr 00.030 is equal to 1 or 2, this value is not transferred to the EEPROM or the drive. If Pr 00.030 is
set to a 3 or 4 the value is transferred.
Parameter string
None
Read
Program
Auto
Boot
For further information, please refer to Chapter 8 Diagnostics on page 52.
00.031
RW Txt
OL
Timed dc I (4), Disable (5)
RFC-A
Timed dc I (4), Disable (5),
Defines how the motor is controlled when the run signal is removed from the drive.
Unidrive M400 Control Quick Start Guide
Issue Number: 3
Ramp Enable
Off (0) or On (1)
Parameter Cloning
Auto (3), Boot (4)
Parameter value
0
1
2
3
4
Stop Mode
Coast (0), Ramp (1),
Ramp dc I (2), dc I (3),
Coast (0), Ramp (1),
Ramp dc I (2), dc I (3),
No Ramp (6)
NC
Comment
Inactive
Read parameter set from the NV Media Card
Programming a parameter set to the NV Media Card
Auto save
Boot mode
US
On (1)
US*
None (0)
US
Ramp (1)
