Control Techniques Unidrive M400 Quick Start Manual page 12

Figure 4-3 Pr 00.005 = AV Preset
10k
Figure 4-4 Pr 00.005 = AI Preset
Current speed
reference input
* Refer to the Control User Guide.
12
1 0V
Voltage speed reference
2
input (AI 1+)
3 AI 1-
4 + 10 V output
Reference select
5
6 0 V
Analog output 1
7
(motor frequency)
Analog output 2
8
(motor active current)
+ 24 V output
9
Digital output
10
(zero frequency)
Unassigned
11
Run forward
12
13 Run reverse
Reference select
14
Terminal 5
15 Jog Forward
16 Unassigned
+ 24 V output
17
1 0V
Current speed reference
2
input (AI 1+)
3 AI 1-
+ 10 V output
4
Reference select
5
6 0 V
Analog output 1
7
(motor frequency)
Analog output 2
8
(motor active current)
+ 24 V output
9
Digital output
10
(zero frequency)
Unassigned
11
Run forward
12
13 Run reverse
Reference select
14
Terminal 5
15 Jog Forward
16 Unassigned
17 + 24 V output
Terminal 14
0 0
0 1
1 0
1 1
Terminal 14
0 0
0 1
1 0
1 1
Unidrive M400 Control Quick Start Guide
Reference selected
Analog reference 1*
Preset speed 2*
Preset speed 3*
Preset speed 4*
Reference selected
Analog reference 1*
Preset speed 2*
Preset speed 3*
Preset speed 4*
Issue Number: 3
