00.053
RW Txt
OL
Ref (0), Forward (1), Reverse (2)
RFC-A
Defines the initial direction of the brake.
Value
0
1
2
See Brake Controller Brake Release in Parameter Reference Guide.
00.054
RW Num
OL
RFC-A
Defines if the brake is applied through zero threshold. See Brake Controller Brake Release in
Parameter Reference Guide.
00.055
RW Txt
OL
RFC-A
Value
0
1
2
3
If Brake Controller Enable (00.055) = Disable, the brake controller is disabled.
If Brake Controller Enable (00.055) = Relay, the brake controller is enabled with I/O set up to control
the brake via the relay output. Drive ok is re-routed to digital I/O.
If Brake Controller Enable (00.055) = Digital I/O, the brake controller is enabled with I/O set up to
control the brake via digital I/O. Drive ok is routed to the relay output.
If Brake Controller Enable (00.055) = User, the brake controller is enabled, but no parameters are set
up to select the brake output.
42
Brake Controller Initial Direction
Brake Controller Brake Apply Through Zero Threshold
0.00 to 25.00 Hz
Brake Controller Enable
Disable (0), Relay (1),
Digital IO (2), User (3)
Ref (0)
Text
Ref
Forward
Reverse
1.00 Hz
Disable (0)
Text
Disable
Relay
Digital IO
User
