Control Techniques Unidrive M400 Quick Start Manual page 39

00.040
RW Num
OL
RFC-A
Set to the number of poles of the motor. The auto mode calculates the number of motor poles from
the settings of Pr 00.007 and Pr 00.039.
00.041
RW Txt
Ur S (0), Ur (1), Fixed (2),
OL Ur Auto (3), Ur I (4), Square (5),
RFC-A
Defines the drive output mode, which can either be a voltage mode or a current mode.
Value Text
0 Ur S
1 Ur
2 Fixed
3 Ur Auto
4 Ur I
5 Square
6 Fixed Tapered
The drive default setting is Ur I mode which means that the drive will carry out an autotune
NOTE
every time the drive is powered-up and enabled. If the load is not going to be stationary
when the drive is powered-up and enabled, then one of the other modes should be
selected. Not selecting another mode could result in poor motor performance or OI ac,
Motor Too Hot or Over Volts trips.
00.042
RW Num
OL
RFC-A
Determines the boost level when Pr 00.041 is set to Fixed, Square or Fixed Tapered modes.
Unidrive M400 Control Quick Start Guide
Issue Number: 3
Number Of Motor Poles
Auto (0) to 32 (16)
Control Mode
Fixed Tapered (6)
Stator resistance and voltage offset measured at each start
No measurements
Fixed boost mode.
Stator resistance and voltage offset measured at first drive enable
Stator resistance and voltage offset measured at each power-up
Square law characteristic
Fixed boost with taper
Low Frequency Voltage Boost
0.0 to 25.0 %
Auto (0)
Ur I (4)
Description
3.0 %
US
US
US
39
