Control Techniques Unidrive M400 Quick Start Manual page 32

00.024
RW Num
OL
RFC-A
This parameter defines the scaling applied to Status Mode Parameter 1 (00.023). The scaling is only
applied in the Status mode.
00.025
RW Num
OL
RFC-A
If any number other than 0 is programmed into this parameter, user security can be applied so that
no parameters except Pr 00.010 can be adjusted with the keypad. When this parameter is read via a
keypad it appears as zero. Refer to the Control User Guide for further information.
00.027
RW Txt
OL
Reset (0), Last (1), Preset (2)
RFC-A
Defines which value of keypad control mode reference is displayed at power-up.
Value Text
0 Reset
1 Last
2 Preset
00.028
RW Txt
OL
Std boost (2), Fast boost (3)
RFC-A
Defines the mode used by the ramp system.
0: Fast ramp
1: Standard ramp
2: Standard ramp with motor voltage boost
3: Fast ramp with motor voltage boost
Fast ramp is linear deceleration at programmed rate, normally used when a braking resistor is
installed.
32
Customer Defined Scaling
0.000 to 10.000
User Security Code
0-9999
Power-up Keypad Control Mode Reference
Keypad reference is zero
Keypad reference is the last used value
Keypad reference is copied from Preset Reference 1 (00.018)
Ramp Mode Select
Fast (0), Standard (1),
1.000
ND NC PT
ND NC PT
Reset (0)
Description
Standard (1)
Unidrive M400 Control Quick Start Guide
US
US
0
US
US
Issue Number: 3
