7.14 R S
ADIO TATUS
The Radio Status menu allows the User to view the condition of various parameters for the radio.
These include RSSI, Battery Level, Accelerometer Orientation and the GPS co-ordinates.
When accessed, the Radio Status menu will open on the RSSI screen. The other parameters can
be viewed by using the ▼ and ▲ keys to select the required screen.
The Radio Status menu is typically located under to Settings menu.

7.14.1 RSSI

The RSSI screen displays the signal quality parameters of the received RF signal. The current
display is in dBm re 50
between –120 dBm and –50 dBm, if the radio has been correctly calibrated. For example, –90
dBm is a strong signal and –130 dBm is no signal.
The RSSI screen will also display the Bit Error Rate (BER) for slots one and two. RSSI and BER
are typically used to indicate signal quality.
The RSSI/BER will be displayed until either the 'Back' key is pressed to return to the next highest
menu level or the 'Select' key is pressed which will return to the main channel menu.

7.14.2 Battery Level

The Battery Level screen displays details of the battery fitted to the radio. The details displayed
include the type of battery, the rating of the battery in milliampere-hours, and the usage time left for
the battery.
Figure 36. Radio Status Menu – Battery Level Screen.
Jul 13 (Iss 1.1)
M
ENU
and 1 mW, and the reading is typically accurate to within ±2 dBm
RSSI
RSSI(dBm): -120
Select
Figure 35. Radio Status Menu – RSSI Screen.
Battery
Type: Smart
Rating: 2300 mAh
Left: 387 min
Select
Page 48
Back
Back
