Simoco SRP8000 SERIES Service Manual

Vhf/uhf portable radio
Hide thumbs
Table of Contents

Advertisement

Quick Links

SRP8000 SERIES
VHF/UHF PORTABLE RADIO
SERVICE MANUAL
TP0332/2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SRP8000 SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for Simoco SRP8000 SERIES

Summary of Contents for Simoco SRP8000 SERIES

  • Page 1 SRP8000 SERIES VHF/UHF PORTABLE RADIO SERVICE MANUAL TP0332/2...
  • Page 2 Introduction Simoco Europe Ltd is a leading manufacturer of professional mobile radio communications with more than fifty years experience of designing, manufacturing, installing and maintaining their product range. With an enviable pedigree, Simoco Europe Ltd leads the field for innovation and quality; is fully...
  • Page 3 SERVICE MANUAL Publication No. TP0332/2 August 1998 Printed in England © Simoco Europe Ltd. 1998 All rights reserved. No part of this publication may be reproduced in any form or by any means without the prior permission of Simoco Europe Ltd.
  • Page 4 It is requested therefore that any errors or omissions noted be advised as follows: Please quote: Please send to: Title of publication Simoco Europe Ltd, TP Ref No Technical Publications Department, Last amendment No. received. P.O. Box 24, Page and/or Figure No.

  • Page 5: Table Of Contents

    SP8000 SERIES VHF/UHF PORTABLE RADIO CONTENTS Page PRELIMINARY PRODUCT SUPPORT POLICY ..........Sevice Concept .
  • Page 6 Page RECEIVER ..............3.4 Antenna Filter .
  • Page 7 Page ALIGNING THE TRANSCEIVER USING THE ALIGNMENT TOOL ..... 4.7 Receiver Tests ............. . 4.7 Sensitivity .
  • Page 8 Page Ancillary Type ............. . C.2 Microphone .
  • Page 9 Page APPENDIX G - USER MEMORY PLUG INTRODUCTION ............. G.1 Terminology .
  • Page 10 LIST OF ILLUSTRATIONS Page Figure 1.1 The SRP8010, SRP8020/21 and SRP8030/31 Portable Radios ....1.1 Figure 2.1 Battery Warning Label ..........2.1 Figure 2.2 Battery Charging Sequence .

  • Page 11: Product Support Policy

    SERVICE PHILOSOPHY Service Concept The SRP8000 series has been designed to provide low cost trunked and non trunked analogue, portable transceivers, using common core electronics, software and interfacing. Once a customer has purchased this equipment, Simoco Europe Ltd. can follow this by providing a ongoing, high level of customer support together with a competitive and professional servicing activity.

  • Page 12: Service Bulletins

    SERVICE BULLETINS Service Bulletins will be issued as necessary to inform Branch Offices of any matter affecting the serviceability of the equipment in the field. (ii) TP0332/2...

  • Page 13: Section 1 - General Information

    Operation of the SRP8000 Series is controlled by settings of the various software parameters. These operating parameters are stored as data in Flash EPROM and these data may be programmed into the radio using an external data programmer, allowing the SRP8000 Series to be customized to the requirements of a particular user.

  • Page 14: Summary Of Data

    SUMMARY OF DATA Note: Typical figures based on normal operating conditions; certain options may modify the figures quoted. General Operation Single and two-frequency simplex. Modulation Frequency, with pre-emphasis. Frequency Bands 68 to 88MHz 138 to 174MHz 440 to 470MHz 335 to 375MHz 403 to 450MHz (Rx), 403 to 440MHz (Tx).

  • Page 15: Transmitter

    Transmitter Switching Bandwidth Full band coverage without degradation. Power Output (into 50 ohms) 4W (E0, Tk and U0 Bands). 5W (AB and R1 Bands). Modulation Distortion Typically 5% with 60% modulation at 1kHz, better than 10% at temperature extremes. Spurious Emission Better than –36dBm (9kHz to 1GHz) Better than –30 dBm (1 to 4GHz).

  • Page 16: Equipment Variation

    EQUIPMENT VARIATION The SRP8000 Series portable radio is ordered using a ten character product code as defined in Table 1.1. For example: PCU0XC01E1 Packed Items - Portable radio, user guide plus 1,6Ahr battery Antenna - 430 to 472MHz ¼ wave whip...

  • Page 17: Ctcss Tone Frequencies

    CTCSS TONE FREQUENCIES Group A Group B Group C Tone Tone Tone Tone Tone 77,0 151,4 71,9 146,2 67,0 88,5 162,2 82,5 156,7 74,4 100,0 173,8 94,8 167,9 79,7 107,2 186,2 103,5 179,9 85,4 114,8 203,5 110,9 192,8 91,5 123,0 218,1 118,8 210,7...

  • Page 18: Section 2 - Commissioning

    SRP8000 SERIES VHF/UHF PORTABLE RADIO SECTION 2 - COMMISSIONING UNPACKING On unpacking, each item should be checked against the contents list and thoroughly inspected for any physical damage. Note: The Company, or its authorized agents, must be advised by letter, within ten days of equipment receipt, of any damage or shortages found.

  • Page 19: Charging The Battery

    GREEN LED Figure 2.2 Battery Charging Sequence The SRP8000 Series Portable Radio is supplied with batteries in their discharged state. Before using the radio, it is necessary to charge the battery using one of the approved battery chargers. This takes approximately one hour, after which the red LED changes to green.

  • Page 20: Fitting The Wrist Lanyard

    The antenna supplied with the radio is the correct length for the frequency band ordered and must be fitted to the mounting boss at the top of the radio (refer to Figure 2.3 step 3). As an option, an uncut antenna may be supplied which will cover a wide frequency band. In this case, the antenna must be cut to the transmitter centre frequency of the frequency band to be used.

  • Page 21: Fitting A Battery

    Fitting a Battery Figure 2.5 Fitting a Battery Locate the battery on the back of the radio with approximately 10mm of the nickel plated metal casting showing. Slide the battery up the radio. When the battery is fully in position, the catch will locate and lock. (Refer to Remove the Battery on page 4.1 for instructions on removing the battery).

  • Page 22: Alphanumeric Characters

    FUNCTION KEYS The key layout and the key functions are described in the relevant SRP8000 Series User Guide. NUMERIC KEYPAD The keypad layout and key functions are described in the relevant SRP8000 Series User Guide.

  • Page 23: Led

    A tri-colour LED is used to indicate the status of the radio. Status Transceiver initializing at Steady Red switch-on Error State Steady Red Recoverable Switch-on Error Red for 2 seconds Switch-on (no error) Green for 2 seconds Transmit Steady Red Busy Flashing Yellow (0,5s on, 0,5s off) Called...

  • Page 24: Audible Alerts

    The SRP8000 Series functionality depends on the customization data which has been loaded. An SRP8000 series radio may be supplied with a ‘Factory Default’, or customer specific customization data. An SRP8000 Series Programmer may be used to customize a radio.

  • Page 25: Section 3 - Technical Description

    VHF/UHF PORTABLE RADIO SECTION 3 - TECHNICAL DESCRIPTION INTRODUCTION The SRP8000 Series is a range of advanced portable radios using the latest modern technology to achieve a very high performance in a small size. Internally the radio consists of: Radio PCB A multi-layer assembly with components mounted both sides.

  • Page 26: Power Supplies And On/Off Control

    POWER SUPPLIES AND ON/OFF CONTROL The main power supply for the radio is the 7,2V battery which is connected directly to the PCB via the battery contacts on the rear of the radio. The power supply has five separate regulators supplying power to the following blocks (see Figure 3.2): VCO PSU +5,6V...

  • Page 27: Figure 3.2 Power Supply Distribution

    IC502 AF_PSU Baseband Regulator Enable VCO_PSU IC502 Frequency Generation Regulator Enable Control TR505 CONT_PSU Baseband TR508 TR507 RX_BIAS Receiver Enable IC400_C VCO_BIAS Frequency Generation BAT+_FS IC501 RF_PSU Receiver Regulator Frequency Generation RX_PSU TR509 PSU_ON Receiver TR501 SWITCH TR527 TR526 RX_ON Control WATCHDOG PULSE TX_PSU...

  • Page 28: Receiver

    RECEIVER Antenna Filter Figure 3.3 on page 3.5 is a block diagram of the receiver and the circuit diagram is shown in Figure 6.8. The antenna low pass filter (L104 to RX_ANT on Figure 6.9) isolates the receiver input during transmissions (D100 forward biased) whilst maintaining a low loss connection from the antenna in the receive state.

  • Page 29: Second Mixer, Second If Amplifier And Ceramic Filters

    First Second 45MHz/ Antenna First Tracking Tracking 21,4MHz First Amplifier Low Pass Band Pass Band Pass Mixer Crystal Filter Filter Filter Filter Low Pass Filter From From Antenna Frequency Switch Generation Second Loop Local Filter Oscillator Ceramic Ceramic Filters Filters 12,5kHz Switch Switch...

  • Page 30: Transmitter

    TRANSMITTER The transmitter block diagram is shown Figure 3.4 and the circuit diagram in Figure 6.9. The transmitter consists of a PA module taking its input from the frequency generation block, and feeding an antenna filter and switch. The transmit power is set by processor control of a DAC in the baseband chip IC701.

  • Page 31: Figure 3.5 Frequency Generation Block Diagram

    LOOP_FILTER and VCAP_BIAS, are compared and the difference between them determines the VCO frequency. Oscillator tuning is by varicap diodes D402 to D405 (receive oscillator) and D407 to D411 (transmit oscillator). Separate wideband VCOs (Rx first local oscillator - TR409, and Tx oscillator - TR413), but a common buffer amplifier (TR410, TR414) are used on all bands.
  • Page 32 The synthesizer, IC401, contains two synthesizer circuits. The second circuit is used for the generation of the receiver second local oscillator (output control signal AUX_CP). This removes the need for the alignment of this oscillator because the frequency is locked to the TCXO and allows its frequency to be varied to avoid potential interference.

  • Page 33: Control Processor System

    CONTROL PROCESSOR SYSTEM The heart of the control processor system consists of the following: H8/3002 Processor (IC600) 32KByte Static RAM (IC601) 512KByte Flash EPROM (IC602) MAX512CSD Triple 10-bit DAC (IC605). The processor controls and monitors the radio functions by a variety of types of digital and analogue interfaces.

  • Page 34: Baseband Audio And Signalling

    The analogue control interfaces are as follows: The processor generates and controls various analogue voltages for receiver and transmitter purposes. IC605 is a triple 10-bit DAC which the processor controls via a 3-wire serial bus. Two of the DAC outputs are used for receiver front-end tuning (RX_TUNE1, RX_TUNE3) and the third for TCXO XL400 frequency trimming.

  • Page 35: Figure 3.8 Baseband Receive Audio Path

    Signalling generation is described in the following section. GC11 EXTERNAL SPEAKER RXOUT1 RXIN GC10 INTERNAL SPEAKER RXOUT2 ALERT TONE GENERATOR SELCALL DETECT RXDAT FFSK RXCLK DETECT CTCSS DETECT SUB_IO Figure 3.8 Baseband Receive Audio Path GC11 SMART I/F AUDIO MIC1_IN TX VCO TXOUT1 INTERNAL MIC...

  • Page 36: Signalling Facilities

    Signalling Facilities The baseband chip has facilities for CTCSS, SELCALL, DTMF and FFSK signalling. The way in which these signalling modes are controlled and how to they relate to the receive and transmit audio paths is described in the following sections. Figure 3.8 is referred to for receive signalling and Figure 3.9 for transmit signalling.

  • Page 37: User Interface

    USER INTERFACE The radio user controls and display facilities that exist on the three product variants is listed in Table 3.3 below. SRP8010 SRP8020 SRP8030 Microphone Loudspeaker Dual Stereo Jack SMART Interface Connector Multi-coloured Status Indicator Rotary Volume and On/Off Control 3 side switches 1 top switch LCD Display...

  • Page 38: Figure 3.11 Smart Interface Block Diagram

    EXT_LSA Baseband EXT_LSB IC701 Mic Input Loudspeaker IC600 Amplifier Mic Audio H8/3002 Processor KEY_DET1 MIC1 ‘Type’ Resistor PTT1 Interrupt IC801_A IC801_B TR804 RXD1 RxD/SDA RXD1_OUT +5V Mic Supply TXD1 TxD/SCL TXD1_OUT TR806-808 TR801-803 Figure 3.11 Smart Interface Block Diagram Connection Signal Name Signal Type Direction...

  • Page 39: Ext_Lsa, Ext_Lsb

    EXT_LSA, EXT_LSB The bridged audio loudspeaker outputs are capable of delivering 500mW into a 16Ω load. MIC1 The combined accessory detect and audio input line MIC1 allows the radio to detect what type of ancillary is connected and the ancillary status (such as key presses). Each ancillary has a ‘type’ resistor that sets up a unique voltage on this accessory detect line which is monitored by the comparator formed by IC801_A and its associated components.

  • Page 40: Mmi Display And Keypad (Not Fitted On Srp8010)

    The KEY_DET3 voltage generated by the different keys is as follows: If the PTT is pressed, KEY_DET3 voltage will still be at 0V If SIDE_KEY1 or SIDE_KEY2 is pressed, each side key generates a unique KEY_DET3 voltage by virtue of resistors in series with each key (R12, R11, R81) in combination with R15 If the ALARM key is pressed, analogue switch IC3 forces KEY_DET3 voltage to the same voltage as the AF_PSU.

  • Page 41: Backlighting

    Four function keys are located below the display: Legend Function Activate menu – Scroll down through channels (or menu, if active) Scroll up through channels (or menu, if active) Confirm choice or action (ie. Enter). The SRP8030 has 12 additional keys (supported by the daughter board) arranged as a DTMF keypad.

  • Page 42: Trickle Charger

    TRICKLE CHARGER The trickle charger uses a positive input on the RxD pin of the smart interface to power a current limited source feeding the battery, limiting the current to approximately 130mA. The charger is enabled by the thermistor in the battery pack, so it is inhibited if a battery pack is not fitted (this is necessary to prevent a voltage at the battery connector which could damage the radio when no battery is present).

  • Page 43: Section 4 - Servicing

    SRP8000 SERIES VHF/UHF PORTABLE RADIO SECTION 4 - SERVICING CAUTION Metal Oxide Semiconductors (MOS) are used in this equipment; therefore the following predictions should be strictly observed, otherwise the devices may become damaged. Device leads should always be in contact with a conductive material to avoid the build-up of static charges.

  • Page 44: Remove The Metal Frame Assembly

    Remove the Metal Frame Assembly (Refer to Figure 4.2) Use a small, flat bladed screwdriver to release the cast metal frame assembly from the bottom of the front casing. This action releases the radio PCB from the MMI PCB. Gently ease the frame assembly out of the front casing taking care not to damage the two flexi-circuits (lift the bottom of the frame so that it just clears the plastic casing, then gently slide the frame away from the top of the casing until it is released from the casing).

  • Page 45: Remove The Radio Pcb

    Figure 4.3 Removing the Metal Screen Remove the Radio PCB (Refer to Figure 4.4) Release the remaining flexi-circuit from the radio PCB as follows: Slide out the locking drawer of the PCB connector, SK6, (on the radio PCB). Use a very small flat bladed screwdriver.

  • Page 46: Remove The Speaker And Microphone

    Remove the Speaker and Microphone (Refer to Figure 4.5) Remove the speaker retaining clip. Lift the speaker / microphone assembly away from the front casing taking care not to damage the flexi-circuit. Figure 4.5 Removing the Speaker / Microphone Assembly Remove the MMI PCB (Refer to Figure 4.6) The MMI PCB is held in place by four plastic lugs on the front casing.

  • Page 47: Re-Assembly

    RE-ASSEMBLY Re-assembly is the reverse of dis-assembly. However: Examine the various seals before re-assembly and replace with new items if necessary. Slight outward deflection of the case walls will ease re-assembly of the MMI PCB behind the retaining lugs. Care must be taken when reconnecting the flexi-circuits to ensure that they are correctly aligned before pressing home the locking drawers on the connectors.

  • Page 48: Test Equipment

    Test Equipment The following is a list of test equipment recommended for carrying out functional tests, setting-up and fault location. Alternative types may be used provided that they are known to have at least equivalent parameters and that corrections are made for any differences in parameters. Test Set Parameters Suitable Type...
  • Page 49 ALIGNING THE RADIO USING THE ALIGNMENT TOOL See Appendix D for details on installing the alignment tool and the use of the associated test equipment. Note: The alignment tool includes comprehensive on-line help text describing how to align the Radio. Receiver Tests Sennsitivity 0,3µV (0,35µV U0 and Tk bands) for 12dB SINAD unweighted.
  • Page 50 SRP8000 SERIES VHF/UHF PORTABLE RADIO SECTION 5 - PARTS LIST Antennae and Batteries Description Part No. Remarks Antenna Helical, E3 Band (67-74MHz) 0000 303 90004 Antenna Helical, E4 Band (74-81MHz) 0000 303 90005 Antenna Helical, E5 Band (81-88MHz) 0000 303 90006...
  • Page 51 Description Part No. Remarks User Memory Plug (UMP) 0000 138 10002 Vehicle Charger PA-VEHA Note: Ancillary items marked with an asterisk ‘ * ’ are non repairable and are NOT to be returned to the Central Repair Unit. Tranceiver Parts Description Part No.

  • Page 52: Figure 6.1 Exploded View Of The Portable Radio

    SRP8000 SERIES VHF/UHF PORTABLE RADIO SECTION 6 - DIAGRAMS ANTENNA ANCILLARY SOCKET COVER FRONT CASE ON/OFF VOL CONTROL SWITCH MAT GASKET LOUDSPEAKER MIC/LS FLEXI L/S CLIP MMI PCB METAL SCREEN TOP FLEXI RADIO PCB FACILITY SOCKET CAST METAL FRAME BATTERY Figure 6.1 Exploded View of the Portable Radio...

  • Page 53: Figure 6.2 Radio Pcb Usage

    Antenna Antenna Filter Part of MMI Filter Smart I/F Tx Power Amp Battery Connections Tx Power Amp 2nd I.F. Loudspeaker Battery Connections Rx Front End Part 2nd L.O. Rx Front End 2nd I.F. 2nd I.F. L.O. Power Tx Buffer Squelch Reference 1st I.F.

  • Page 54: Figure 6.3 Radio Pcb Component Layout Diagram - Side

    5,6 MAX 4,0 MAX 7,8 MAX (3 POS) (3 POS) 2,8 ±0,3 101,0 ±0,2 ( 9,78° ) 109,46 ±0,2 1,5° ±1° 124,0 ±0,3 MAIN ASSEMBLY SIDE 1 (TOP) Figure 6.3 Radio PCB Component Layout Diagram - Side 1 TP0332/2...

  • Page 55: Figure 6.4 Radio Pcb Component Layout Diagram - Side

    MAIN ASSEMBLY SIDE 2 (BOTTOM) Figure 6.4 Radio PCB Component Layout Diagram - Side 2 TP0332/2...

  • Page 56: Figure 6.5 Pcb Connector Circuit Diagram

    MMI CONNECTOR LCD_CS KEY_ROW1 AF_PSU KEY_ROW2 RX_BIAS BLITE BAT+_FS KEY_DET3 A(20) OPTIONS CONNECTOR KRY_DET2 TXD1 CONT_PSU RSSI_TX_TEMP RXD1 PTT2 LIMI COMPEX LIM0 COMP1 EXPI SDDA SQUELCH TOP CONTROL FLEXIBLE CIRCUIT CONNECTOR KEY_ROW1 EXT_LSA MIC1 EXT_LSB TXD1_OUT RXD1_IN SWITCH AF_PSU ROT_CTRL1 R84 100 BAT+_FS SIDE_KEY2...

  • Page 57: Figure 6.6 Radio Pcb Circuit Diagram

    Figure 6.6 Radio PCB Circuit Diagram TP0332/2...

  • Page 58: Figure 6.7 Power Supplies Circuit Diagram

    Figure 6.7 Power Supplies Circuit Diagram TP0332/2...

  • Page 59: Figure 6.8 Receiver Circuit Diagram

    Figure 6.8 Receiver Circuit Diagram TP0332/2...

  • Page 60: Figure 6.9 Transmitter Circuit Diagram

    Values of these components are frequency dependent. Figure 6.9 Transmitter Circuit Diagram 6.10 TP0332/2...

  • Page 61: Figure 6.10 Frequency Generation Circuit Diagram

    Figure 6.10 Frequency Generation Circuit Diagram TP0332/2 6.11...

  • Page 62: Figure 6.11 Baseband Circuit Diagram

    Figure 6.11 Baseband Circuit Diagram 6.12 TP0332/2...

  • Page 63: Figure 6.12 Control Circuit Diagram

    Figure 6.12 Control Circuit Diagram TP0332/2 6.13...

  • Page 64: Figure 6.13 Smart Interface Circuit Diagram

    Figure 6.13 SMART Interface Circuit Diagram 6.14 TP0332/2...

  • Page 65: Figure 6.14 Top Control Flexi Circuit Diagram

    ALARM PL1_1 Alarm Button KEY_ROW1 PL1_2 EXT_LSB PL1_3 MIC1 PL1_4 2,5mm EXT_LSA PL1_5 SK1_B Jack Sockets SK1_A TXD1_OUT PL1_6 3,5mm RXD1_IN PL1_7 PL1_8 Top Control Flexible RV1_B Circuit Connector PL1_9 AF_PSU PL1_10 AF_PSU RV1_A Volume Control PL1_11 ROT_CTRL1 BAT+_FS PL1_12 BAT+_FS PL1_13 SIDE_KEY2...

  • Page 66: Figure 6.15 Mmi Pcb Component Layout Diagrams

    D906 D905 D904 D907 D914 D917 D918 TR912 R995 R935 TR915 R934 R972 R996 R973 R994 TR913 TR910 TR909 TR918 C915 R974 R977 IC901 R955 R998 R954 R941 TR916 C917 TR907 R979 C901 IC903 C906 R957 TR917 C910 R948 C918 IC900 PL900 PL901...

  • Page 67: Figure 6.16 Mmi Pcb Circuit Diagram

    Figure 6.16 MMI PCB Circuit Diagram TP0332/2 6.17...
  • Page 68 INT_LSB PL1_1 LOUDSPEAKER T036S23A0001 INT_LSA PL1_2 PL1_3 PL1_4 Loudspeaker and Microphone Flexible Circuit Connector PL1_5 PL1_6 C1000 WM-62B MICROPHONE 100p MIC1 MIC2 PL1_7 Figure 6.17 Loudspeaker / Microphone Flexi Circuit Diagram 6.18 TP0332/2...

  • Page 69: Figure A.1 Desk-Top And Multi-Unit Battery Chargers

    SRP8000 SERIES VHF/UHF PORTABLE RADIO APPENDIX A - BATTERY CHARGERS Single-pocket Desk-top Charger with PSU Two-pocket Desk-top Charger Six-pocket Multi-unit Charger Ten-pocket Multi-unit Charger Power Supply Unit Figure A.1 Desk-top and Multi-unit Battery Chargers INTRODUCTION WARNING This equipment is designed to meet relevant safety requirements.
  • Page 70 The chargers can accept: Single Pocket One battery. Desk-top Charger One radio with battery fitted. Two pocket Two batteries. Desk-top Charger Two radios with batteries fitted. One radio with battery fitted and one battery. Multi-unit Charger Six Pocket Ten Pocket Six batteries.
  • Page 71 OPERATION Each pocket of all charger units will accept a battery without radio, or a radio complete with battery. Radio with Battery To charge a battery connected to a radio, insert the radio into a charger pocket with the front of the radio towards the front of the charger.
  • Page 72 LED Indications (except single unit charger) Each charging pocket has a tri-colour LED to indicate the charger/battery status: Colour Indication Status Amber Power indicator Power on Green Battery ready Charging complete Battery not ready Charging Fault indication LED flashing, and colour, indicates fault: Invalid battery type Flashing amber Battery too hot...

  • Page 73: Figure B.1 Lapel Loudspeaker / Microphone

    SRP8000 SERIES VHF/UHF PORTABLE RADIO APPENDIX B - LAPEL SPEAKER / MICROPHONE Figure B.1 Lapel Loudspeaker / Microphone INTRODUCTION The lapel loudspeaker / microphone is a robust, lightweight, unit with an integral press-to-talk (PTT) switch and a headset socket. The unit connects to the portable radio via a 1,5m ‘curly’ cable with a 2,5mm (J1) and 3,5mm (J2) stereo jack plugs mounted in a single moulding.

  • Page 74: Figure B.2 Lapel Speaker / Microphone Circuit Diagram

    Loudspeaker Impedance 16Ω ±2Ω. Power rating 0,3W nominal, 0,5W maximum. Headset socket 3,5mm - loudspeaker disconnected when jack inserted. Environmental Operating temperature range –20°C to +55°C. Storage temperature range –40°C to +80°C. white Headset Jack Mylar (2,5mm) Loudspeaker 160Ω 0,3W –...
  • Page 75 PARTS LIST Description Part No. Remarks Lapel LS/Mic, complete 0000 242 10001 TP0332/2...

  • Page 76: Figure C.1 Headset

    Figure C.1 Headset INTRODUCTION The headset supported by the SRP8000 series portable radio is a single earpiece headset with boom microphone, in-line PTT switch and a VOX PTT function. The headset is connected to the portable radio via a 1,5m straight cable with a 2,5mm (J1) and 3,5mm (J2) stereo jack plugs mounted in a single moulding.

  • Page 77: Figure C.2 Headset Circuit Diagram

    Earpiece Impedance 16Ω ±2Ω. Power rating 3mW continuous per earpiece, 10mW maximum. Environmental Operating temperature range –10°C to +55°C. Storage temperature range –40°C to +80°C. R6 150R Earpiece SW1 Manual/VOX PTT Switch BAV99 2,5mm Stereo R5 5k6 Plug SW1b Adjust 150R NJM2072D 0µ1...
  • Page 78 INTRODUCTION Purpose of this Section This section will help with the installation of the SRP8000 Series Alignment Tool. It lists the equipment required and how to set-up the PC to get optimum performance from the Alignment Tool. It also describes how to get started in connecting and aligning a radio.
  • Page 79 Software Requirements The PC must have an operating system that is compatible with the Alignment Tool. Compatible operating systems are Microsoft Windows™ version 3.1 or Windows 95. Notes: (i) The Alignment Tool will not run on Windows NT™ . (ii) It is not possible to install or use the Alignment Tool without one of these compatible Windows systems running.

  • Page 80: Figure D.1 Installation Progress Indicators

    Note that the tool should not be used until the computer has been re-started. When Windows is restarted, a Program Group named ‘SRP80 series Tools’ is displayed containing a Program Item ‘SRP80 series Alignment Tool’. This group may already contain the SRP8000 Series Programmer (if previously installed). TP0332/2...
  • Page 81 Installation Warnings Warnings that could occur during installation are shown in Table D.2. Warning Stage Occurring Action to Take Lack of Disk After installation drive and directory Free at least 10Mb of hard disk space Space have been selected before continuing with installation File In Use When installation or Windows Close any Windows applications that are...
  • Page 82 Alignment Tool Application window is displayed. It is possible to run the SRP8000 Series Programmer at the same time as the Alignment Tool; however, if both tools have the same serial communication port defined, one of these tools may lock out the serial port preventing its use by the other tool.
  • Page 83 To navigate the on-line Help using the keyboard, use the Tab key to move between highlighted topics. If you are unsure of the meaning of a term, select the Glossary key to display a list of terms. More assistance on using on-line Help may be accessed through the item How to Use Help on the Help window’s Help menu.
  • Page 84 If there are questions or problems, regarding the Alignment Tool, that cannot be answered using the On-line Help (see Using On-line Help on page D.5), support is available from Simoco Europe Ltd. Information on how to obtain the latest upgrades of Alignment Tool software is available also.
  • Page 85 If there are any comments regarding the Alignment Tool software, On-line Help or this section of the Service manual, it is requested that they are passed to the following address: SRP8000 Series Product Support Simoco Europe Ltd P O Box 24...
  • Page 86 Figure E.1 Trickle Charge Power Supply INTRODUCTION The SRP8000 series trickle charge power supply is an AC mains powered module with a two metre charging lead terminating in a 3,5mm mono jack plug. The mains power plug is an integral part of the module.
  • Page 87 Mechanical Weight Less than 300g. Supply Input Connections 13A 3-pin with plastic earth pin. Euro 2-pin. US 2-pin. Charging Connections Positive Tip of 3,5mm jack plug. Negative - Sleeve of 3,5mm jack plug. Environmental Storage Temperature : –30° to +85° C. Operational Temperature : 0°...

  • Page 88: Figure F.1 Programming Lead

    Figure F.1 Programming Lead INTRODUCTION The SRP8000 series portable radios are programmed via a PC serial port. A connecting cable (programming lead) is required. The PC end terminates in a 9-pin ‘D’ Type female connector and the radio end terminates in a 3,5mm and a 2,5mm stereo jack housed in a common moulding.

  • Page 89: Figure F.2 Programming Lead Circuit

    9-pin ‘D’ type 3,5mm Jack Plug 300 ohm, 0,125W (mounted inside ‘D’ type housing) 2 TxD 3 RxD 5 Ground 2,5mm Jack Plug 270 ohm, 0,125W (mounted inside ‘D’ type housing) Dual-jack moulding Figure F.2 Programming Lead Circuit PARTS LIST Description Part No.

  • Page 90: Figure G.1 User Memory Plug

    SRP8000 SERIES VHF/UHF PORTABLE RADIO APPENDIX G - USER MEMORY PLUG Figure G.1 User Memory Plug INTRODUCTION The User Memory Plug (UMP) is used to transfer a radio customization from the radio to the UMP (store customization data), and from the UMP to the radio (update or reload customization).

  • Page 91: Figure G.2 User Memory Plug Circuit

    DESCRIPTION The UMP provides 8Kb x 8 of non-volatile memory, accessed by the IIC bus. The memory address is A0 (Hex) BAT54CW x 3 AT24C64N-10SI 3,5mm Jack Plug 1µF 2,5mm Dummy Jack Plug Figure G.2 User Memory Plug Circuit PARTS LIST Description Part No.

  • Page 92: Figure H.1 Vehicle Mount Attachment

    Figure H.1 Vehicle Mount Attachment INTRODUCTION The Vehicle Mount Attachment is used to allow the SRP8000 series portable radio to be used in a vehicle and powered / trickle charged from the vehicle battery. The vehicle mount attachment consists of a moulding (holster) and a one metre long power lead.

  • Page 93: Figure H.2 Vehicle Mount Attachment Circuit

    Holster Vehicle Cigar Lighter Plug (DIN ISO4165) Power Lead (1 metre) –ve Contacts in base of holster Figure H.2 Vehicle Mount Attachment Circuit CAUTION A radio that is switched-off should NOT be left on trickle charge for more than 24 hours. CAUTION Do NOT attempt to charge a battery when the battery temperature is below 0°...

  • Page 94: Figure I.1 Prp70 Charger Pocket Adaptor

    SRP8000 SERIES VHF/UHF PORTABLE RADIO APPENDIX I - PRP70 CHARGER POCKET ADAPTOR Portable Radio Charger Pocket Adaptor PRX7001 Desk-top Charger Figure I.1 PRP70 Charger Pocket Adaptor INTRODUCTION Using the PRP70 Charger Pocket Adaptor, batteries can be charged in PRX7001 or PRX7005 battery chargers.
