SDP660 – USER MANUAL
To return to the Messages Menu, press the 'Back' key.
7.7.2

Outbox

The Outbox is used to store the transmitted (sent) messages. Up to 20 messages can be stored in
the outbox. These messages are volatile, which means that, at radio start-up, the outbox will be
empty.
For each sent message, the Outbox displays either details of the recipient from the Contacts list or,
if the ID is not known to the Contact list, the recipient's UID. If no messages are stored, 'No
Messages' is displayed.
To scroll through the stored messages, use the▼ and ▲ keys.
Pressing the 'Select' key will display the selected Message. Pressing the 'Select' key again will
give 'Reply' and 'Delete' options.
To return to the Messages Menu, press the 'Back' key.
7.7.3

Send Status

The Send Status menu option can be used to send a short Status message to another party. Up to
10 Status lists, each containing up to 250 status message entries can be created and pre-
programmed into the radio using the FPP. Each status message entry consists of a unique
Number and Text. Each Number may range from 0 to 1023. One status list may be attached to
each zone-channel.
The information displayed on the Send Status message screen shows the unique number and the
text of the status message.
To select a different Status message, use the▼ and ▲ keys to scroll through the programmed
status messages. Each Status message will be displayed in turn.
Jul 13 (Iss 1.1)
Outbox
SDM 202
Disp 600
Disp 600
Select
Figure 22. Messages – Outbox.
Send Status
1
Status One
Select
Figure 23. Messages – Send Status.
Page 41
Back
Back
MENU SCREENS
TNM-U-E-0114
