FRONT PANEL CONTROLS

The SDP660 portable Radio has the following features:
Multiple programmable dedicated function buttons and a numeric keypad.
•
Function buttons and numeric buttons can also have a second programmable function
•
provided by a longer button press.
Multi-coloured LED for a clear indication of radio status.
•
Full colour display with intuitive interface.
•
The Controls of the SDP660 Portable radio are shown below in Figures 5.
Jul 13 (Iss 1.1)
1
2
3
6
9
7
8
10
11
16

Figure 5. SDP660 Controls.

Page 22
TNM-U-E-0114
5
4
Nav
13
Up
14 Nav
Nav Nav
Right
Left Select
12
Nav
Down
15
