SDP660 – USER MANUAL
7.12 S V
PEAKER OLUME
The Speaker Volume Menu allows the user to set the radio start-up value of the audio volume
control for user comfort. The 'Speaker Volume' menu is located under the Options menu.
The level can be set in 33 steps over the range 0 to 32, with 0 (zero) delivering no sound, 16 is
normal level and 32 giving the maximum possible output from the speaker.
Use the ▼ and ▲ keys to select the relative speaker volume level. A beep will sound at the
indicated level each time the setting is changed.
To accept and save the setting and return to the previous screen, press the 'Select' key.
7.13 A V
LERT OLUME
The Alert Volume menu allows the user to set the offset of the Alert Volume in relation to the
current Volume setting. Thus, the alert tones can be made louder or softer than the main voice
audio.
The 'Alert Volume' menu is located under the Options menu.
The level can be set in 33 steps over the range 0 to 32, with 0 (zero) being about the same as the
voice level.
Use the ▼ and ▲ keys to select the relative alert volume level. A beep will sound at the indicated
level each time the setting is changed.
To accept and save the setting and return to the previous screen, press the 'S' key.
Note.
A minimum Alert Level may be set by the FPP to ensure that the Alerts can always be
heard from the speaker.
Jul 13 (Iss 1.1)
M
ENU
Spkr Volume
3
4
5
6
7
Select
Figure 33. Speaker Volume Menu.
M
ENU
Alert Volume
3
4
5
6
7
Select
Figure 34. Alert Volume Menu.
Page 47
