SDP660 – USER MANUAL
7.7 M M
ESSAGES
A radio unit can receive and transmit predefined short messages and text messages with another
radio unit on a DMR channel.
The Messages menu allows the user to view a preset menu screen which allows the radio user to
check the state of the various digital message systems in the radio. The message system sub-
menus are: Inbox, Outbox, Send Status, Send Template, and New Message.
Received messages are stored in the 'Inbox'. Transmitted messages are stored in the 'Outbox'.
Both can be viewed and deleted as required.
If there are unread messages stored in the radio, the
screen.
Use the ▼ and ▲ keys to scroll through the Messages menu options. Press the 'S' key to access
the required option.
7.7.1

Inbox

The Inbox is used to store the received messages. Up to 20 messages can be stored in the Inbox.
These messages are volatile, which means that, at radio start-up, the inbox will be empty.
For each received message the Inbox displays either details of the sender from the Contacts list or,
if the ID is not known to the Contact list, the sender UID.
Messages' is displayed.
To scroll through the stored messages, use the▼ and ▲ keys.
Pressing the 'Select' key will display the selected Message. Pressing the 'Select' key again will
give 'Reply' and 'Delete' options.
Jul 13 (Iss 1.1)
ENU
Messages
Inbox
Outbox
Send Status
Send Template
New Message
Select

Figure 20. Messages Menu.

Inbox
SDM 202
Disp 600
Disp 600
Select
Figure 21. Messages – Inbox.
Page 40
icon will be displayed on the default
Back
Back
If no messages are stored, 'No
MENU SCREENS
TNM-U-E-0114
