SDP660 – USER MANUAL
Press the 'Back' key to return to the previous screen.
Press the 'Select' key to display the Send screen, which allows you to select a Contact from the
Contacts menu. See Para 6.7.6 – Sending Status, Template and Text Messages for further
information.
7.7.4
Send Template
The Send Template menu option can be used to send a pre-formed message. Up to 100 template
messages may be configured by the FPP. Each template is a pre-formed message text.
The Send Template menu is only displayed if the FPP has configured one or more templates.
To select a different Template message, use the▼ and ▲ keys to scroll through the programmed
messages.
Press the 'Select' key to display the Send screen, which allows you to select a Contact from the
Contacts menu. See Para 6.7.6 – Sending Status, Template and Text Messages for further
information.
7.7.5
New Message
The New Message menu option can be used to create, edit and send short text messages.
Each message can be up to 160 characters in length. The number of remaining characters that
can be entered is displayed above the message.
Text characters are entered using the keypad. Each keypad button is labelled with up to 4 text
characters (e.g. 7 = PQRS). The text characters are entered by pressing the keypad once for the
first character, twice for the second, and three times for the third, and so on.
After a short delay, the cursor will advance to the next character entry. Entered characters are
inserted immediately to the right of the cursor.
Jul 13 (Iss 1.1)
Send Templat
Hello
Select
Figure 24. Messages – Send Template.
New Message
160
Select
Figure 25. Messages – New Message.
Page 42
Back
Back
MENU SCREENS
TNM-U-E-0114
