SDP660 – USER MANUAL
The functions of each of the controls are detailed below in Table 3.
Table 3. SDP660 – Controls.
No. Control
1 Tx/Rx/Power LED
2 Volume
3 Earpiece
4 Antenna
5 Function Key F5
6 Function Key F6
7 PTT
8 Function Key F13
9 LCD Display
10 Function Key F1
11 Function Key F11
12 Function Key F12
13 Function Key F4
14 Nav-Up F7
Nav-Down F8
Nav-Left F9
Nav-Right F10
Nav-Select
15 Numeric Keypad
16 Microphone
The details of the multi-coloured LED indications are contained below in Table 4.
Table 4. LED Indications.
LED Colour
LED Off. Radio is in idle state (no call activity).
Green Receiving a valid incoming signal.
Green Flashing Radio in talk-back hang time. (FPP defined parameter for digital channel).
Red Radio is transmitting.
Red Flashing Emergency Mode active. This is a FPP defined parameter
Orange Flashing Low Battery.
Jul 13 (Iss 1.1)
Label
Multi coloured LED. See Table 4 below for full details of colour
indications.
Multifunction knob. Provides volume control (rotate clockwise to
increase the volume; counterclockwise to decrease the volume). Also
provides channel and zone selection, in conjunction with side-buttons
F6 and F13.
Prog. function key. Default – Emergency/Alarm.
Prog. function key. Assignable key for Zone or Channel browsing.
Push To Talk. Hold the radio 10 cm from the mouth. Press and hold
the PTT switch and speak. Release the PTT switch to listen.
Prog. function key. Assignable key for Zone or Channel browsing.
Menu Prog. function key. Default – Menu Select.
Prog. function key. Default – Start Call, Send Message.
Prog. function key. Default – End Call, Cancel, power On/Off.
Mon Prog. function key. Default – Mon (Monitor).
▲ Prog. function key. Default – Up key for scrolling.
▼ Prog. function key. Default – Down key for scrolling.
◄ Prog. function key. Default – Left key for scrolling.
► Prog. function key. Default – Right key for scrolling.
Select Default – Function Select.
Used to enter Idents, send text messages and set status.
