Options Menu; Contacts Menu; Figure 15. Options Menu; Figure 16. Contacts Menu - Simoco SDP660 User Manual

SDP660 – USER MANUAL
Radio Status; or
•
User Options.
•
7.4 O M
PTIONS ENU
The Options menu allows the user access to a preset selection of menu options for user radio
interface configuration items. These include the backlight timeout period, the backlight brightness,
speaker and alert tone volume control limitations, and the key beeps function.
Using the ▼ and ▲ keys, scroll through the available Options menu items. Press the 'Select' key
to access the menu option required.
If required, these user option functions can also be assigned directly to the radio's function buttons.
Information on each of the Options menu items is contained later in this section.
7.5 C M
ONTACTS
The Contacts Menu allows user to select the communication entity they wish to call, e.g. individual
radio unit (UID or SUID), talk group of radio units (TGID), dialled external network access gateway
(phone, internet, other radio networks, dispatchers), and PABX/PSTN.
Up to 20 Contact Lists can be created and programmed into the Radio with the FPP. Each
Contact List can have up to 600 entries. Each Contact List is assigned on a per "Channel" basis in
the Zone set up section of the FPP.
Therefore, the Contact list displayed via the Contact menu is the Contact List assigned to the
radio's currently selected Channel. This ensures that a user can't select a Contact who uses a
different mode than the one selected.
Use the ▼ and ▲ keys to scroll through the available contacts. Pressing the 'Select' key will
display the details for the selected contact (see Figure 17 overleaf).
Jul 13 (Iss 1.1)
Options
Brightness
Backlight
Key Beeps
Spkr Volume
Alert Volume
Select

Figure 15. Options Menu.

ENU
Contacts
Grp 9003
Grp 9004
Control
Security
Tech 1
Select

Figure 16. Contacts Menu.

Page 38
Back
Back
MENU SCREENS
TNM-U-E-0114
