SDP660 – USER MANUAL
7.2 Z M
ONE ENU
The Zone menu is used for changing Zones. A Zone is normally defined as a group of radio
channels with a common operational role.
Once the 'Zone' menu appears, press the ▼ and ▲ keys to choose the required Zone. Press the
'Select' key to select the required Zone. The radio will return to the channel screen and select the
first channel in the new Zone.
Direct access to the 'Zone' menu from other screens can also be programmed to one of the
function buttons with the FPP.
7.3 S M
ETTINGS ENU
The Settings Menu allows the user to access a programmable selection of the menu options from
which they can edit/modify the operation of some of the general functions of the radio.
The Settings menu options can be programmed into the Settings menu with the FPP. The FPP
User can choose to add any, all or none of the menu options to the Settings menu as required. If
the Settings menu option is not included in the Main Menu list, the Settings Menu will not be
accessible to the radio user.
Using the ▼ and ▲ keys, cycle through the available Settings menus options. Press the 'Select'
key to access the menu option required.
Using the ▼ and ▲ keys, scroll through the available Settings Sub-menus.
The Setup menu structure may include, for example:
Information (Radio software and hardware information);
•
Mute Adjust;
•
Jul 13 (Iss 1.1)
Zone
Zone1
Zone2
Zone3
Zone4
Zone5
Select

Figure 13. Zone Menu.

Settings
Mute Adjust
Radio Status
Information
Help
Display Test
Select

Figure 14. Settings Menu (example).

Page 37
Back
Back
MENU SCREENS
TNM-U-E-0114
