SDP660 – USER MANUAL
7

MENU SCREENS

The menu structure on the SDP660 Portable Radio is configurable using the FPP. A system
administrator usually tailors the order and presence of the menu options to specific customer
requirements.
This section describes all the menus that are currently available.
Normally, the menus are divided into three menu lists. These are the Main Menu list, the Settings
Menu list and the Options Menu list.
In the default configuration, the Main menu contains the Channel, Zone and Settings menus. This
allows access to the second 'Settings' menu level.
The Main Menu can be accessed from the main default screen by selecting the 'Menu' (F1) button.
To access any of the menu options from the Main, Settings or Options Menus, use the ▲ and ▼
keys to scroll through the lists until the required menu option is selected with the leading pointer (>)
and then press the 'Select' (Nav Select) button.
Pressing the 'Back' (F4) button at any point will go back to the previous screen.
7.1 C M
HANNELS
The Channels menu allows the user to select the communication channel to be used within a
Zone. An example of the Channels menu screen is shown below in Figure 12.
The Channel Screen shows the currently selected channel. To change to another channel, use the
▲ and ▼ keys or the Rotary Encoder to move the leading pointer to the required channel and
press the 'Select' button.
The channel can also be changed from the main default screen simply by using the ▲ and ▼ keys
Radio channels may be configured with the FPP as specific frequencies or as auto-scan types.
When an auto-scan channel is selected, it will immediately go into scan mode. Selecting another
non-auto-scan channel will stop the scan.
Jul 13 (Iss 1.1)
ENU
Channels
Zone1
D 453.975 1w
D 453.975 5w
D 463.475 5w
D 463.475 1w
Select

Figure 12. Channels Menu.

Page 36
Back
MENU SCREENS
TNM-U-E-0114
