SDP660 – USER MANUAL
2.1.4
Fitting the Belt Clip
Align the belt clip with the grooves of the belt clip housing on the back of the battery. Push the belt
clip downwards until a click is heard.
2.1.5
Fitting Audio Accessory/Programming Cable
1
On the side of the radio, release the retaining screw and remove the accessory socket cover.
2
On the audio accessory/programming cable, locate the tab lug of the connector into either
the top or bottom tab hole on the side of the radio as required (see Figure 4 below).
3
Tighten the screw to secure the audio accessory/programming cable to the radio.
Figure 4. Fitting Audio Accessory/Programming Cable.
2.2
C
ONFIGURATION
Before the SDP660 radio can be used it must be configured using the Field Personality
Programmer (FPP). The configuration process loads the customised channels, signalling and user
options so that the radio will operate with the user's system.
Jul 13 (Iss 1.1)
Figure 3. Fitting the Belt Clip.
Top
Tab
Tab
Lug
Hole
Page 21
TNM-U-E-0114
GETTING STARTED
