2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN12
CN13
CN14
CN15
CN17
ATX1
SATA1
USB1
USB2
SCFAST1
SCN1
SDIMM1
SJ1
12
TM
D2550/N2800/N2600 Processor 3.5" SBC
Description
Front Panel Connector
Digital I/O Connector
SMBus Connector
USB Wafer Port 4 and 5
COM2 Connector
Power Output Connector
CPU Fan Connector
COM1 Connector
Audio Connector
Inverter Connector
LVDS Connector
Ethernet Port 1 and 2
HDMI Connector
VGA Connector
Power Connector
Serial ATA Connector
USB Port 2 and 3
USB Port 0 and 1
TM
CFast
PCI-Express Mini Card and mSATA Connector
DDR3 SO-DIMM Connector
ZIO Expansion Connector
Socket
Board and Pin Assignments
