UG-609
GETTING STARTED
SOFTWARE INSTALLATION PROCEDURES
The evaluation board software can be downloaded from the
AD7903
product page on the Analog Devices website, at
www.analog.com.
There are two parts to the installation:
•
AD7903
evaluation board software installation
•
EVAL-SDP-CB1Z
system demonstration platform board
drivers installation
Warning
The evaluation board software and drivers must be installed
before connecting the evaluation board and
board to the USB port of the PC to ensure that the evaluation
system is correctly recognized when it is connected to the PC.
Installing the
AD7903
Evaluation Board Software
To install the
AD7903
evaluation board software,
1.
Start the Windows operating system and download the
software from the
AD7903
Devices website, at www.analog.com.
2.
Unzip the downloaded file.
3.
Double-click the setup.exe file to begin the evaluation
board software installation (see Figure 2).
Figure 2.
AD7903
Evaluation Board Software Installation: Installation Begins
EVAL-SDP-CB1Z
product page on the Analog
4.
Select the location to install the software, and then click
Next. (The default location is C:\Program Files (x86)\
Analog Devices\AD7902_03 Evaluation Software\.
This location also contains the executable software and
example files.)
Figure 3.
Selecting the Location for Software Installation
5.
A license agreement appears. Read the agreement, and then
select I accept the License Agreement and click Next.
Figure 4.
Rev. 0 | Page 4 of 32
EVAL-AD7903SDZ User Guide
AD7903
Evaluation Board Software Installation:
(the Default Location Is Shown)
AD7903
Evaluation Board Software Installation:
Accepting the License Agreement
