EVAL-AD5592RSDZ User Guide
EVALUATION BOARD CIRCUITRY
The
AD5592R
evaluation board allows the function and
performance of the device to be easily tested. The evaluation
board contains two voltage regulators that not only generate the
analog and digital power supplies but also power the
board if it is connected. The two regulators are powered via a
6 V supply attached to Connector J3. Alternatively, a separate
supply can be attached via Connector J2.
The
SDP-B
board typically controls the
attached to Connector J4. The
SDP-B
AD5592R
and is
SDP-B
board allows the software
provided with the kit to be used to configure the
well as write and read data to and from the AD5592R.
When the
SDP-B
applied to the
AD5592R
pins on Connector J5.
In addition to the on-chip reference of the AD5592R, an
external, 2.5 V reference is also provided and can be connected
to the V
pin of the
REF
Rev. 0 | Page 7 of 13
is not required, the control signals can be
by connecting them to the relevant
AD5592R
using Link LK3.
UG-753
AD5592R
as
