UG-683

EVALUATION BOARD CIRCUITRY

SOCKETS/CONNECTORS

The connectors and sockets on the
described in Table 3.
Table 3. On-Board Connectors
Connector Function
J1 Analog input AIN+
J2 Analog input AIN−
J3 MCLK input—standalone mode
J4 MDAT output—standalone mode
J5 V external source
DD1
J6 V external source
DD2
J7 V external source—high voltage
DD1
EVAL-AD7403FMCZ are
Rev. 0 | Page 10 of 20
EVAL-AD7403FMCZ User Guide
The default interface to this evaluation board is via the FMC
connector, which connects the
EVAL-SDP-CH1Z board. If the
used in standalone mode, communication is achieved via the J3
and J4 SMB jacks. See Table 2 for more information about
configuring the evaluation board for standalone mode.

TEST POINTS

There are several test points on the
board. These test points provide easy access to the signals from
the evaluation board for probing, evaluation, and debugging.
EVAL-AD7403FMCZ to the
EVAL-AD7403FMCZ board is
EVAL-AD7403FMCZ
