EVAL-AD5629RSDZ/EVAL-AD5669RSDZ User Guide
EVALUATION BOARD CIRCUITRY
The
EVAL-AD5629RSDZ/EVAL-AD5669RSDZ
boards easily test the function and performance of the
AD5629R/AD5669R.
Control of the
AD5629R/AD5669R
the
SDP-B
board, which is attached to Connector J3. The
board allows the software provided with the kit to load register
values, set the voltage of the DAC outputs, and write to the
control register of the AD5629R/AD5669R.
evaluation
is typically performed by
SDP-B
Rev. 0 | Page 7 of 14
When the
SDP-B
board is not required, the control signals can
be applied to the
AD5629R/AD5669R
the relevant SMB Connector J6 to Connector J9.
The DAC output voltages are available on the SMB Connector A to
Connector H.
UG-867
by connecting them to
