EVALUATION BOARD CIRCUITRY

SOCKETS AND CONNECTORS

The connectors and sockets on the EVAL-AD7383FMCZ are
described in Table 3.
Table 3. On-Board Connectors
Connector Function
J1 Negative analog input for Channel A (A
J2 Positive analog input for Channel A (A
J3 Negative analog input for Channel B (A
J4 Positive analog input for Channel B (A
P1 Amplifier mezzanine card inputs
P2 Amplifier mezzanine card outputs
P3 Digital SPI signals
P4 Main board power supply (12 V) for all internal
voltage regulators
P5 ADC power supply and digital SPI power supply
P6 Amplifier power supply
P7 Field programmable gate array (FPGA) mezzanine
card (FMC) to low pin count (LPC) connector
EXTREF External voltage reference
EVAL-AD7383FMCZ
The default interface to the EVAL-AD7383FMCZ is achieved
via the 160-way connector. The connector attaches the EVAL-
AD7383FMCZ to the SDP-H1. When using the EVAL-
AD7383FMCZ in standalone mode, communication is achieved
via the P3 header pins.

TEST POINTS

A−)
IN
There are several test points and single in line (SIL) headers on
A+)
IN
the EVAL-AD7383FMCZ. These test points provide access to
B−)
IN
the signals from the EVAL-AD7383FMCZ for probing, evaluation,
B+)
IN
and debugging.
