Geeetech Duplicator 5 Assembly Manual page 72

Hide thumbs Also See for Duplicator 5:
Table of Contents

Advertisement

Required parts
Required number
Part ID
Pic.
Motor wire
1
NO. 60
3-1
Step 1. Connect one end of the X/Y/Z motor wires with the control board.
Step 2. Thread X axis motor wire (the longest one) through the hole at the angle
of the front panel and right side one. Connect it with X axis motor.
71
