Sticker
M3*16mm Screw
M3 Washer
Step 1. Cut5 rectangular scraps of the stick according to the size of the heat sink.
Stick the 5 scraps to 5 heat sinks orderly. Subsequently, attach the heat sinks to 5
A4988 chips respectively.
Step 2. Insert 4 spacers into the 4 corresponding corners on the control board.
2
NO. 43
4
NO. 17
4
NO. 5
64
