Required parts
Upper panel
Z axis bearing
fixed panel
M3*16mm Screw
Hex nut
M3 Washer
Attach the Z axis bearing fixed panel to the inside of the upper panel with
2xM3*16mm screws, 2xM3 hex nuts and 2 washers.
Required number
1
1
2
2
2
20
Part ID
NO. D5
NO. D7
NO. 17
NO.11
NO. 5
Pic.
