5 Remote Control of the P30

The P30 Remote Control application is intended for controlling the Leica ScanStation P30
remotely via WiFi by a:
Leica Viva Controller (CS10 or CS15 equipped with a WiFi adapter)
•
Apple iPad, iPod, iPhone or any
•
Android device
•
On the Leica ScanStation P30, that should be controlled remotely, the firmware version 1.20 or
later has to be installed. The remote control will not work with former firmware versions.
The remote control solutions for all devices will be explained one by one.

5.1 Remote Control with Leica CS10 and CS15

The following hardware is needed
Leica Viva Controller (CS10 or CS15) equipped with a WiFi adapter.
•
Check the sticker "This device contains..." in the battery compartment of the Leica Viva
Controller. In case a WLAN module is listed, the controller is equipped with a WiFi adapter.
Leica ScanStation P30 laser scanner
•

Software installation

Copy the installation file "P30_RemoteControl.CAB" onto a USB memory device. For detailed
installation information please see the Remote Control Manual for the Leica Viva controllers.

Enabling the WiFi adapter

With the CS10/CS15 controller go to
•
Double-click on "Network and Dial-up Connections".
•
Select the icon of the WiFi device (e.g. "NXPWLAN1") and press "File".
•
If the menu lists "Disable", the WiFi device is already enabled.
•
In this case leave the control panel without any changes.
•
If the menu lists "Enable", press "Enable" and leave the Control Panel.
•

Establish connection to the ScanStation P30

Switch on the Leica ScanStation P30 and wait for the boot process to finish.
46 - 60 Module 1.0 - Scanning with ScanStation P30
Start | Settings | Control Panel.
Scanner & Scanning Features
